PPSU Board

  • 1. Excellent long term hydrolysis stability
  • 2. Very high impact strength
  • 3. High operating temperature of 180℃
  • 4. Dimensional stability at high temperature
  • 5. Withstands repeated steam sterilization
  • 6. Inherently flame retardant

Share this:

Overview :

PPSU board is commonly used in applications where components are required to operate at higher temperatures due to the materials resistance to hydrolysis. Furthermore, PPSU plastic board delivers the highest performance of our sulfone polymers. Polyphenylsulfone board also provides excellent resistance to radiation, superior mechanical strength, very high impact strength and chemical resistance.



General Dimensions of PPSU Board

LENGTH (mm) WIDTH (mm) HEIGHT (mm) TOLERANCE MAX (mm) WEIGHT  (KG)
1250 620 4 +2 5.1
1250 620 6 +2 7.14
1250 620 8 +2 9.18
1250 620 10 +2 11.22
1250 620 15 +2 16.32
1250 620 20 +2 21.42
1250 620 25 +2 26.52
1250 620 30 +2 31.62
1250 620 35 +2 36.73
1250 620 40 +2 41.83
1250 620 45 +2 46.93
1250 620 50 +2 52.03
1250 620 60 +2 62.23
1250 620 70 +2 72.43
1250 620 80 +2 82.63
1250 620 90 +2 92.83
1250 620 100 +2 103.04



Please contact us and ask for special dimensions.

Typical Application

Automobile Industry

Aerospace

Household Appliance

FAQ:

Whether to provide the sample and the delivery time of the sample ?

We can provide a sample of 3kg in stock within 5 working days.

Q1

Can you provide customized services?

Yes, all our raw materials can be customized, such as adding glass fiber, carbon fiber and other fillers, or making boards and rods of different sizes. Click for details to learn more>>

Q2

Can you provide the quality certificate of the products?

Of course. All of our products are proven to be perfectly compliant with FDA, REACH and RoHS safety regulatory, and so on. If you need, you can contact us to check the relevant documents.

Q3

Are you manufacturer or trading company?

We are integral part of industry and trade. Both the agency of some products, but also a factory for product development and production.

Q4

About bulk order leading time?

It will take about 15~30 working days from order confirmation to production completion. Specific communication can be coordinated to the time acceptable to both side.
