PEEK Rod CF Filled

  • 1. Superior resistance to hydrolysis
  • 2. Good chemical resistance
  • 3. High rigidity and dimensional stability
  • 4. Exceptional stiffness and creep strength
  • 5. Extremely strong and wear resistant
  • 6. Good electrically conductive and heat conductivity

Share this:

Overview :

PEEK Rod CF is a carbon filled PEEK material. The carbon fiber reinforced PEEK polymer has higher stiffness and creep strength. Carbon fiber reinforced PEEK has very high mechanical strength values, while the density is lower than that of glass fiber filled PEEK in the same proportion. Carbon filled PEEK maintains all the significant benefits of natural PEEK material such as good dimensional stability, superior chemical resistance and high resistance to creep. Carbon filled PEEK rod also has exceptional hydrolysis resistance in boiling water and superheated steam. About the size of carbon filled PEEK rods, in addition to the regular size, we also provide customized service, just tell us your demands, we will try our best to meet it.



General Dimensions of PEEK Rod CF Filled

DIAMETER (mm) LENGTH (mm) TOLERANCE MAX (mm) WEIGHT  (KG/M)
6 1000 +2 0.07
8 1000 +2 0.10
10 1000 +2 0.15
15 1000 +2 0.30
20 1000 +2 0.50
25 1000 +2 0.75
30 1000 +2 1.05
35 1000 +2 1.41
40 1000 +2 1.82
45 1000 +2 2.27
50 1000 +2 2.78
60 1000 +2 3.95
70 1000 +2 5.33
80 1000 +2 6.91
90 1000 +2 8.70
100 1000 +2 10.70
150 1000 +2 23.76
200 1000 +2 41.96



Please contact us and ask for special dimensions.

Typical Application

Automobile Industry

Aerospace

Household Appliance

FAQ:

Whether to provide the sample and the delivery time of the sample ?

We can provide a sample of 3kg in stock within 5 working days.

Q1

Can you provide customized services?

Yes, all our raw materials can be customized, such as adding glass fiber, carbon fiber and other fillers, or making boards and rods of different sizes. Click for details to learn more>>

Q2

Can you provide the quality certificate of the products?

Of course. All of our products are proven to be perfectly compliant with FDA, REACH and RoHS safety regulatory, and so on. If you need, you can contact us to check the relevant documents.

Q3

Are you manufacturer or trading company?

We are integral part of industry and trade. Both the agency of some products, but also a factory for product development and production.

Q4

About bulk order leading time?

It will take about 15~30 working days from order confirmation to production completion. Specific communication can be coordinated to the time acceptable to both side.
